ASROCK H81M-VG4 R2.0 (VGA, SOCKET 1150)
THÔNG TIN SẢN PHẨM
– Mã hàng: H81M
– Bảo hành: 36 Tháng
– Hãng sản xuất: ASRock
– Xuất xứ: Chính Hãng
MÔ TẢ SẢN PHẨM
Hỗ trợ Bộ xử lý Intel ® Xeon ® / Core ™ i7 / i5 / i3 / Pentium ® / Celeron ® thế hệ thứ 4 và thứ 4 mới (Socket 1150)
100% toàn bộ thiết kế tụ điện rắn
Hỗ trợ kênh đôi DDR3 / DDR3L 1600
1 PCIe 2.0 x16, 1 PCIe 2.0 x1, 1 D-Sub
100% toàn bộ thiết kế tụ điện rắn
Hỗ trợ kênh đôi DDR3 / DDR3L 1600
1 PCIe 2.0 x16, 1 PCIe 2.0 x1, 1 D-Sub
Mô tả
-
CPU– Supports New 4th and 4th Generation Intel® Core™ i7/i5/i3/Xeon®/Pentium®/Celeron® Processors (Socket 1150)
– Supports Intel® Turbo Boost 2.0 Technology -
Chipset– Intel® H81
-
Bộ nhớ RAM– Dual Channel DDR3/DDR3L Memory Technology
– 2 x DDR3/DDR3L DIMM Slots
– Supports DDR3/DDR3L 1600 / 1333/1066 non-ECC, un-buffered memory
– Max. capacity of system memory: 16GB*
– Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2*Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation. -
BIOS– 32Mb AMI UEFI Legal BIOS with multilingual GUI support
– ACPI 1.1 Compliant wake up events
– SMBIOS 2.3.1 support
– CPU, DRAM Voltage multi-adjustment -
Card đồ họa– Supports Intel® HD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel® InTru™ 3D, Intel® Clear Video HD Technology, Intel® Insider™, Intel® HD Graphics 4400/4600*
– Pixel Shader 5.0, DirectX 11.1
– Max. shared memory 1024MB*
– Supports D-Sub with max. resolution up to 1920×1200 @ 60Hz*Intel® HD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated.**The size of maximum shared memory may vary from different operating systems.
-
Card âm thanh– 7.1 CH HD Audio (Realtek ALC887/897 Audio Codec)
– Supports Surge Protection -
LAN– PCIE x1 Gigabit LAN 10/100/1000 Mb/s
– Realtek RTL8111H
– Supports Wake-On-LAN
– Supports Lightning/ESD Protection
– Supports Energy Efficient Ethernet 802.3az
– Supports PXE -
Khe cắm– 1 x PCI Express 2.0 x16 Slot (PCIE2: x16 mode)
– 1 x PCI Express 2.0 x1 Slot -
Kho tiền– 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug
– 2 x SATA2 3.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug -
Cổng kết nối– 1 x Chassis Intrusion and Speaker Header
– 1 x TPM Header
– 1 x SPI TPM Header
– 1 x CPU Fan Connector (4-pin)
– 1 x Chassis Fan Connector (4-pin)
– 1 x 24 pin ATX Power Connector
– 1 x 4 pin 12V Power Connector
– 1 x Front Panel Audio Connector
– 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)
